Dual-camera, Live face detection

8-inch All-sight LCD Touch Screen

Anti-backlight, with resolution of 1280*800


IP65, can endure harsh outdoor environment

Up to 99.99% Recognition Accuracy

All-metal case

Embedded card reader, Wi-Fi



Product Parameters


General Parameters

  • Working temperature： -10℃~50℃
  • Power：DC 12V/2A
  • Working humidity：10%～90%
  • Power consumption：Max. 12W
  • Protection grade： IP65

Display

  • Display screen： 8-inch IPS all-sight LCD touch screen
  • Resolution：1280 * 800

RGB Camera

  • Image sensor： 1/2.7" 2MP COMS HD WDR camera
  • CMOS: 1/2.7" 2MP CMOS HD WDR camera
  • Resolution：1932 * 1092
  • Shutter type：Electronic rolling shutter
  • AGC balance：Auto
  • WDR: 120dB
  • FOV：74.38°
  • AEC balance：Auto
  • AWB balance: Auto
  • Lens：f=4.35mm, Aperture F2.

Infrared Camera

  • Image sensor: 1/2.7" 2MP CMOS HD WDR camera
  • Resolution：1932 * 1092
  • Shutter type：Electronic rolling shutter
  • AGC balance：Auto
  • Lens： f=4.2mm, Aperture F1.6
  • WDR :120dB
  • FOV: 67.57°
  • AEC balance： Auto
  • AWB balance：Auto

System Parameters

  • Operating system： Linux
  • Storage：1GB RAM, 8GB ROM
  • CPU：Dual-core ARM Cortex-A7@ 900MHz

Interfaces

  • RS-232, Wiegand26/34 output, Relay output, TTL output, Tamper switch, USB Type A

Communication Mode

  • Wi-Fi, RJ-45

Functions

  • Accuracy：Up to 99.99%
  • Type of card reader : Standard MIFARE card
  • Recognition distance configuration: Live detection: 0.3-1.5m; Non-live: 0.3-3m
  • Remote upgrade： Supports
  • Capacity: 100-thousand face database
  • Records: 1 million pieces of recognition records
  • Custom UI：Supports
  • Software： Cloud, LAN
